Overall W x L:
96" x 174"
-
Deck W x L:
72" x 120"
-
Gate W x L:
69" x 50"
-
Empty Weight:
696 lbs.
-
Payload Capacity:
2,294 lbs.
-
Coupler:
2" A-Frame, Bolt-On, Zinc (CPL2-BOLTON)
-
Tongue:
A-Frame 4" Aluminum Channel
-
Length: Frame to Coupler:
47"
-
Level Tongue Height:
16-3/4"
-
Jack:
2,000 Lbs. Top-Wind, Zinc (742)
-
Safety Chains:
Class II, 30" x 1/4" w/ Hooks (639T)
-
Wiring Connector:
4-Way Flat
-
Frame:
2" x 3" x 1/4" Aluminum Angle
-
Crossmembers:
2" x 2" x 1/4" Aluminum Angle
-
Uprights:
1-1/4" x 2-1/2" Aluminum Tube
-
Upright Height:
14" H
-
Sides:
Open
-
Top Rail:
1-1/4" x 2-1/2" Aluminum Tube
-
Flooring:
2x Dimensional Treated Wood
-
Deck Ht. from Ground:
19-1/2"
-
Tie-Down Points:
4 Aluminum Stake Pockets
-
Fenders:
9" x 32" Aluminum Round w/ Back (ALFENDER9X32)
-
Axle:
Single 3,500 Lbs. E-Z Lube, 84"/70" (3K8470EZ)
-
Suspension:
3-Leaf Springs Eye-to-Eye (504T)
-
Tires:
15" ST205/75D15 Bias (205X15SILVER)
-
Wheels:
Silver Mod, 5 on 4-1/2"
-
GVWR:
2,990 Lbs.
-
Gate Style:
Removable Ramp Gate
-
Rear Latch:
Aluminum J-Pin w/ Spring
-
Tail Lights:
LED Stop/Turn/Tail Light (Opt_STL79R1B)
-
Marker Lights:
LED Amber Penny Light (881T)
-
Clearance Lights:
LED Red Penny Light (880T)
-
ID Lights:
LED 3-Light ID Bar (438T)
-
License Plate Illumination:
License Plate Light (834T)
