Model Information:

  • Overall W x L: 92" x 191"
  • Bed W x L: 72" x 144"
  • Gate W x H: 73" x 20"
  • Empty Weight: 3,100 lbs.
  • Payload Capacity: 8,900 lbs.
  • Floor: Steel, 11 Ga.
  • GVWR: 12,000 lbs.
  • Volume Capacity: 4 yd.
  • Axle 1: 6,000 lb. Drop Axle w/ Brake
  • Axle 2: 6,000 lb. Drop Axle w/ Brake
  • Breakaway Kit Included: Yes
  • Leaf Springs: 5
  • Floor: 6" Channel
  • Upright Height: Integrated
  • Top Rail: 18" H, 14 Ga. Steel
  • Roof Frame On Center: 5" Channel Wrapped A-Frame
  • Tongue Extension: 2-5/16" A-Frame
  • Coupler: 5,000 lb. Rated Top Wind
  • Jack: 16" Radial LT235XR16
  • Tires: White Mod
  • Wheels: Steel
  • Fender Wells, Inner: ?
  • Lights: 48"
  • Front Vertical Stone Guard: 30"
  • Deck Height: Combination Spreader/Tail Gate
  • Rear Gate Style: ?
  • Curbside Entry Door W x H: 4" x 30"
  • Hydraulic Cylinder: Gravity Down
  • Hydraulic Operation: 12v with Remote Control
