Overall W x L:
96" x 222"
-
Deck W x L:
72" x 168"
-
Gate W x L:
73" x 49"
-
Empty Weight:
1,190 lbs.
-
Payload Capacity:
5,810 lbs.
-
Coupler:
2-5/16" A-Frame, Bolt-On, Zinc
-
Tongue:
A-Frame 6" Aluminum Channel
-
Length: Frame to Coupler:
48-3/4"
-
Level Tongue Height:
17-1/2"
-
Jack:
2,000 Lbs. Top-Wind, Zinc (742)
-
Safety Chains:
GVWR 7,600 Lbs., 30" x 5/16" w/ Hooks
-
Wiring Connector:
7-Way Round
-
Frame:
2" x 6" x 1/4" Aluminum Angle
-
Crossmembers:
3" Aluminum Channel
-
Uprights:
1-1/4" x 2-1/2" Aluminum Tube
-
Upright Height:
14"
-
Sides:
Open
-
Top Rail:
3" x 2" x 1/4" Aluminum Angle
-
Flooring:
2x Dimensional Treated Wood
-
Deck Ht. from Ground:
19"
-
Tie-Down Points:
4 Aluminum Stake Pockets
-
Fenders:
9" x 67" Tandem Aluminum Round w/ Back
-
Axle:
Two 3,500 Lbs. Brake Axles w/ E-Z Lube 88"/74-1/2" (3K8874EZ)
-
Suspension:
3-Leaf Springs Eye-to-Eye (504T) w/ Eye-to-Eye Tandem Equalizer (510T)
-
Tires:
15" ST205/75D15 Bias (205X15SILVER)
-
Wheels:
Silver Mod, 5 on 4-1/2"
-
GVWR:
7,000 Lbs.
-
Gate Style:
Removable Ramp Gate
-
Rear Latch:
Aluminum J-Pin w/ Spring
-
Tail Lights:
LED Red Stop/Turn/Tail Lights (Opt_STL79R1B)
-
Marker / Clearance Lights:
LED Amber Penny Light (881T) LED Red Penny Light (880T)
-
ID Lights:
LED 3-Light ID Bar (438T)
-
License Plate Illumination:
License Plate Light (834T)
