10K Tandem Axle Equipment Trailer

This extremely versatile trailer comes in a wide range of sizes and configurations, so you can find the exact right fit for your equipment. It's truly customizable for whatever you're hauling, whether it's longer and you need a flatbed or more valuable and could benefit from a dovetail deck. No matter the load, you can count on this trailer to get the job done.

Available Sizes

  • 7' x 16'
  • 7' x 18'
  • 7' x 20'
Arrow/ white
View Models
  • GVWRGroup Copy 2?: 9,990 lbs.
  • Empty Weight: 2,560 - 2,880 lbs.
  • Payload CapacityGroup Copy 2?: 7,110 - 7,430 lbs.
  • Leaf Springs: 5
  • Frame: 5" Channel
  • Uprights: Front Stop Rail 2.5" x 2.5" Angle
  • Uprights Height: 12"
  • Top Rail: Front Stop Rail 2.5" x 2.5" Angle
  • Tongue: 5" Channel A-Frame
  • Coupler: 2-5/16" A-Frame
  • Jack: 2,000 lb. Rated Top Wind
  • Tires: 15" ST225x15
  • Wheels: White Mod
Capacity and construction varies by model. See individual model information pages for complete details.

Models

  • Model: 7X16HDEQDTFR
  • Overall W x L: 102" x 238"
  • Bed W x L: 82" x 192"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,560 lbs.
  • Payload Capacity: 7,430 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X18HDEQDTFR
  • Overall W x L: 102" x 262"
  • Bed W x L: 82" x 216"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,720 lbs.
  • Payload Capacity: 7,270 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X18HDEQFTSR
  • Overall W x L: 102" x 262"
  • Bed W x L: 82" x 216"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,720 lbs.
  • Payload Capacity: 7,270 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X18HDEQDTSR
  • Overall W x L: 102" x 262"
  • Bed W x L: 82" x 216"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,760 lbs.
  • Payload Capacity: 7,230 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X18HDEQFTFR
  • Overall W x L: 102" x 262"
  • Bed W x L: 82" x 216"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,760 lbs.
  • Payload Capacity: 7,230 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X20HDEQDTFR
  • Overall W x L: 102" x 286"
  • Bed W x L: 82" x 240"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,880 lbs.
  • Payload Capacity: 7,110 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X20HDEQDTSR
  • Overall W x L: 102" x 286"
  • Bed W x L: 82" x 240"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,880 lbs.
  • Payload Capacity: 7,110 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X20HDEQFTFR
  • Overall W x L: 102" x 286"
  • Bed W x L: 82" x 240"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,880 lbs.
  • Payload Capacity: 7,110 lbs.
  • Floor: Wood, Treated 2x8
  • Model: 7X20HDEQFTSR
  • Overall W x L: 102" x 286"
  • Bed W x L: 82" x 240"
  • Gate W x H: 16" x 60"
  • Empty Weight: 2,880 lbs.
  • Payload Capacity: 7,110 lbs.
  • Floor: Wood, Treated 2x8

Find your trailer in
a store near you

Arrow/ white
Find a Dealer

Features

DOVETAIL DECK

Our dovetail deck makes loading vehicles or equipment easier. Using either fold-up or slide-in ramps, our trailers with dovetail decks allow for a smoother transition when moving from terrain to trailer.

FOLD-UP OR SLIDE-IN RAMPS

Tired of removing your ramps and carrying them to your trailer's rear? With slide-in ramps, loading and unloading has never been more convenient. Simply open a latch, slide the ramps out, and place them on the support bar—that's it, you're done. Plus, when slide-ramps are not in use and out of the way, you can store longer cargo on your trailer.

REAR STABILIZER JACKS

When unloading and loading, rear stabilizer jacks help make your trailer level and secured, especially when loading heavy equipment from the rear. Simply pull on the hitch pin to lower or raise drop legs into place, and then reinsert pins to stabilize loading—keeping both you and cargo out of harm's way.
